Switch Tamping & Lining Machine & Plasser & Theurer 08-275 Unimat 3S

Model : 08-275 UNIMAT 3S

Country Mfd : AUSTRIA

Gauge : 1435 mm

Engine : SCANIA,D112, 543hp @ 1500rpm

Coupling Type : 85, UIC standard

Max load/axle : 20 ton

Tamping Unit : 2x sleepers tamping units of 32 tines each

Operation :

– Tamping of 2 sleepers per circle
– Tamping of Switches and Crossings and Plain Line
– Synchronous 3-rail lifting unit in both sides

Max Speed (Self propelled) : 80 km/h

Max Speed (train formation) : 100 km/h

Dimensions (LxWxH) : 2027 x 2910 x 3240 mm

Weight (without Material Car) : 75 ton

Weight of Material Car : 8.5 ton
